Commercial Sectional Overhead Doors By Clopay®
Halo Overhead Doors is Houston's Master Authorized Clopay commercial dealer — carrying the complete lineup of Clopay commercial sectional overhead doors from entry-level Industrial Series through the high-performance Extreme™ Series. As a Master Authorized dealer, Halo offers the full Gold Bar extended warranty, the largest Clopay showroom in Houston with 60+ full-size doors on display, and factory-certified installation on every job. Whether you need a rugged no-frills industrial door for a warehouse receiving dock, a high-R-value Intellicore® door for a climate-controlled facility, or a high-speed Extreme™ door for a fire station or car dealership, the right Clopay commercial sectional door is in our lineup. All series feature Clopay's Tog-L-Loc® joining system, commercial-grade hardware, and WindCode® reinforcement options critical for Houston's wind load requirements. Every Clopay commercial sectional door is backed by Clopay's industry-leading warranties — and when installed by Halo as your Master Authorized dealer, you receive the Elite Gold Bar extended warranty covering both parts and labor.
BY:
Models
| Industrial Series — Steel Sectional Doors | ||
| Non-Insulated & Insulated | ||
| Model | Type | Description |
|---|---|---|
| 520 / 520S | Ribbed Steel | 20-gauge ribbed steel. Non-insulated (520) or polystyrene insulated (520S, R-6.6). Deep rib profile for added strength. Ideal for warehouses and loading docks. |
| 522 / 522S | Flush Steel | 20-gauge flush steel. Non-insulated (522) or polystyrene insulated (522S, R-6.6). Clean flush panel design. Suits commercial buildings requiring a modern look. |
| 524 / 524V / 524S | Ribbed Steel | 24-gauge ribbed steel. Non-insulated (524), vision lite (524V), or polystyrene insulated (524S, R-6.6). Injection-molded lite frames with integral weatherseal. Tog-L-Loc® joining system. |
| 525 / 525V / 525S | Heavy Ribbed Steel | Heavy-duty ribbed steel. Non-insulated (525), vision lite (525V), or polystyrene insulated (525S, R-6.6). Heavier gauge construction for high-cycle or demanding industrial applications. |
| 664 / 664V | Raised Panel Steel | Contemporary raised panel steel. Non-insulated (664) or vision lite (664V). Provides a traditional aesthetic for commercial buildings where appearance matters. |
| Energy Series — Polystyrene Insulated | ||
| R-6.5 to R-9.1 | ||
| Model | Thickness / R-Value | Description |
|---|---|---|
| 3150 | 1-3/8″ thick · R-6.5 | 27-gauge exterior steel, R-6.5 polystyrene insulation. Energy-efficient entry-level insulated commercial door. Stucco or woodgrain embossed exterior. |
| 3200 / 3211 / 3233 | 2″ thick · R-9.1 | 24-gauge steel, bonded polystyrene insulation, R-9.1. Stucco or woodgrain embossed exterior. Ideal for warehouses, loading docks, and agricultural facilities. |
| 3220 | 2″ thick · R-9.1 | Rugged 24-gauge commercial door with R-9.1 polystyrene insulation. Designed for demanding industrial facilities. Extended 8-Year Hardware Warranty available. |
| Energy Series with Intellicore® — Polyurethane Insulated | ||
| R-12.9 to R-18.4 | ||
| Model | Thickness / R-Value | Description |
|---|---|---|
| 3715 | 1-1/2″ thick · R-12.9 | Foamed-in-place Intellicore® polyurethane, R-12.9. Steel exterior. Available with 24″ × 12″ windows and full-view sections. WindCode® available to DP52. |
| 3717 / 3718 | 1-3/4″ thick · R-16.2 | Intellicore® polyurethane insulation, R-16.2. Stucco or woodgrain embossed steel exterior. Exceptional climate control for manufacturing plants and municipal buildings. |
| 3720 / 3721 / 3723 | 2″ thick · R-18.4 | Intellicore® polyurethane insulation, R-18.4. Multiple section designs and embossed textures. Full-view Intellicore® sections available on 3720. Up to 32’2″ wide standard. |
| 3722 | 2″ thick · Flush Steel | Flush steel with Intellicore® polyurethane. Designed for demanding conditions requiring a rugged, energy-efficient door. Full-view Intellicore® sections available. |
| 3724 | 2″ thick · Durable | Durable, versatile, and easy-to-maintain Intellicore® door for commercial and industrial use. Full-view Intellicore® sections available. |
| 3730 | 2″ thick · High R-Value | High R-value Intellicore® door for facilities where maximum energy efficiency, ease of maintenance, versatility, and durability are all required. |
| Extreme™ Series — High Performance Sectional Door | ||
| 24″/sec · High Cycle | ||
| Model | Performance | Description |
|---|---|---|
| Extreme™ | High Performance | Opens at 24 inches per second — 3× faster than standard commercial doors. Powered by LiftMaster. 5× spring life, tandem nylon rollers, 3′ light curtain, cable tension monitor. Intellicore® insulated and non-insulated versions available. |
Installation & R-Value Comparison
Houston’s climate makes insulation performance one of the most important factors in commercial door selection. A higher R-value means less heat transfer — lower HVAC costs, better temperature control, and a more comfortable working environment. Here’s how the Clopay commercial lineup compares.
What insulation level does your facility need?
| Non-Insulated | Industrial Series 520, 522, 524, 525, 664 — Best for open-air or non-climate-controlled facilities, agricultural buildings, storage. Most economical. |
| R-6.6 Polystyrene | Industrial 520S/522S/524S/525S — Adds basic insulation; reduces noise and temperature swings in light-use commercial applications. |
| R-9.1 Polystyrene | Energy Series 3150–3220 — Substantial energy savings for warehouses, loading docks, manufacturing, and distribution. Good value choice for Houston’s heat. |
| R-12.9 to R-18.4 Polyurethane | Intellicore® Series 3715–3730 — Maximum thermal performance. Foamed-in-place polyurethane also adds structural rigidity. Best for climate-controlled facilities, cold storage, and buildings where HVAC costs are significant. |
| High Performance | Extreme™ Series — When speed and cycle count matter more than insulation value. Reduces heat infiltration through rapid opening/closing. |
Option & Upgrades
Glass & Windows
- Window sizes: 24″ × 12″ (most models) · 19½” × 12″ (3721/3723) · Full-view sections (3715, 3717, 3718, 3720, 3722, 3724)
- Glass types: Clear · Gray tinted · Bronze tinted · Mirrored · Obscure · Frosted · White laminate glass
- Glazing materials: Glass (1/8″, 1/4″, 1/2″) · Clear/gray/white acrylic · Tri-wall polycarbonate (5/8″) · Low-E insulated glass available
- Full-view Intellicore® sections with polyurethane insulated aluminum frames — available on models 3720, 3722, 3724
Hardware & Spring Upgrades
- Spring cycle upgrades: Standard 10,000 · 25,000 · 50,000 · 100,000 cycles — specify based on daily usage frequency
- Nylon tire rollers upgrade — quieter operation with longer roller life vs. steel rollers (standard on Extreme™)
- 10-gauge end hinges and heavy-duty top bracket upgrade — commercial high-performance hardware for demanding applications
- 3″ sealed roller with 5/8″ stem — high-performance roller option for smoother, longer-lasting operation
- Extended 8-Year Hardware Warranty — available on select models for maximum protection on demanding commercial applications
Track & Structural Options
- Track types: Standard lift · High lift · Full vertical lift · Low headroom (front or rear mount) · Follow the roof pitch · Combination
- 2″ or 3″ track width — 3″ track recommended for heavier doors and larger openings
- WindCode® reinforcement — available up to W8 Design Pressure (DP) 52 PSF; doors tested 50% above rated DP. Critical for Houston’s coastal and inland wind zones.
- Pass door — personnel access door built into the overhead door section; eliminates need for a separate walk-through opening
- Mullions — carry-away, roll-away, or swing-up mullions on select sizes for wide openings
- Break-away sections — single or double section break-away for vehicle impact protection on dock openings
- Exhaust port — can be cut into any type of solid sectional door for vehicle exhaust ventilation in service bays
Finish & Color Options
- Standard colors: White · Almond · Desert Tan · Sandtone · Bronze · Chocolate · Gray · Charcoal · Mocha · Black · Trinar® White
- Color Blast™ program — over 1,500 Sherwin-Williams® color options for perfect brand or building color matching; backed by Clopay’s 5-year finish warranty
- Exterior panel designs: Stucco embossed · Woodgrain embossed · Flush smooth · Deep ribbed · Raised panel — varies by series
- Tog-L-Loc® joining system standard on Industrial and Energy Series — eliminates welds and rivets for rust and leak prevention
Features & Benefits
Standard Hardware — All Commercial Series
- 14-gauge hinges — commercial grade for demanding daily use
- Commercial 10-ball steel rollers standard — nylon tire rollers available as upgrade
- 10,000-cycle torsion springs standard — upgradeable to 25k, 50k, or 100k cycles
- Steel step plate and lift handle for easy manual operation
- Inside slide lock for increased security when door is closed
- 19-gauge steel hinge support plates — 18-gauge single end stiles; 16-gauge double end stiles
- Galvanized aircraft cables with 7:1 safety factor — industry-leading safety margin
- 2″ or 3″ track in a variety of configurations to accommodate your building design
| Industrial Series — Construction Details | |
| Technical Specifications & Performance Features | |
| Category | Specification |
|---|---|
| Panel Gauge | 20-gauge (520/522) or 24-gauge (524/525) prepainted galvanized steel — inside and out for virtually maintenance-free finish |
| Panel Thickness | 2″ (all Industrial models) |
| Insulation | Environmentally safe polystyrene conformed to panel with 30-gauge prepainted steel back cover (S models only) — R-6.6 |
| Joining System | Tog-L-Loc® — eliminates welds and rivets; improves rust and leak prevention |
| Lite Frames | Injection-molded lite frames with integral weatherseal — durable and seal against elements |
| Rust Warranty | 10-year warranty against rust-through |
| Energy Series with Intellicore® — Construction Details | |
| Thermal Efficiency & Structural Performance | |
| Category | Specification |
|---|---|
| Intellicore® Insulation | Proprietary foamed-in-place polyurethane — injected into the door, expands to fill entire structure. Creates incredible strength and structural rigidity in addition to thermal performance. |
| R-Values | R-12.9 (3715) · R-16.2 (3717/3718) · R-18.4 (3720/3721/3723) — all per DASMA TDS-163 |
| Panel Thickness | 1-1/2″ (3715) · 1-3/4″ (3717/3718) · 2″ (3720 series/3722/3724/3730) |
| WindCode® | Available up to W8 Design Pressure (DP) 52 PSF. Doors are tested 50% greater than rated DP. Essential for Houston’s wind load requirements. |
| Max Width | Up to 32’2″ wide standard. Consult factory for larger sizes. |
| Extreme™ Series — High Performance Specs | |
| Speed · Safety · Durability | |
| Category | Specification |
|---|---|
| Opening Speed | 24 inches per second — 3× faster than a standard commercial door |
| Spring Life | 5× the spring life of an average commercial sectional door |
| Operator | Powered by LiftMaster commercial operator |
| Rollers | Tandem nylon rollers — improved roller life and reduced running noise |
| Safety | 3-foot light curtain protection standard · Cable management system · Standard cable tension monitor |
| Frame | 2-1/8″ commercial-grade aluminum frame — virtually maintenance-free; tongue-and-groove with integral joint seal |
| Best For | Fire stations · Emergency services · Car dealerships · Distribution centers · High-cycle warehouses · Any application where door speed drives operational efficiency |
Applications & Ideal Use Cases
Clopay’s commercial sectional door lineup covers virtually every commercial and industrial application in Greater Houston. Here’s what each series is best suited for:
- Warehouses: Energy Series R-9.1 or Intellicore® for climate-controlled; Industrial Series 520/524 for non-insulated receiving docks.
- Loading Docks: Industrial Series or Energy Series with WindCode® — durable daily-cycle performance with weather sealing for dock openings.
- Fire Stations: Extreme™ Series — designed with fire stations in mind. 24″/sec opening keeps apparatus moving with zero delay.
- Auto Dealerships: Extreme™ Series or Intellicore® with full-view windows — rapid access, aesthetic appeal, and climate control for showrooms and service bays.
- Distribution Centers: Extreme™ for high-cycle dock doors; Intellicore® 3720/3722 for insulated cross-dock and climate-controlled sections.
- Cold Storage: Intellicore® R-18.4 models (3720/3721/3723) deliver the highest thermal performance for refrigerated and frozen storage applications.
- Commercial Buildings: Energy Series or Intellicore® with Color Blast™ for service entrances and receiving docks that also need curb appeal.
- Municipal & Schools: Energy Series — durable, low-maintenance sectional doors for public works facilities, fleet maintenance, and school gymnasiums.
- Manufacturing: Industrial or Energy Series for production floor access. High-cycle spring upgrades available for doors operating multiple shifts daily.
- Home Builders: Clopay is the preferred door for Houston-area homebuilders. Halo is a GHBA and TAB member — the local expert for builder programs.
- Retail & Hospitality: Intellicore® with full-view or Color Blast™ options for retail service entrances, hotel service areas, and restaurant receiving.
- Aviation & Hangars: Full vertical lift track option and high-cycle springs for hangar doors and aviation maintenance facilities near Houston’s airports.
Why Halo Overhead Doors
- Master Authorized Clopay Dealer — highest Clopay dealer tier; access to the full commercial lineup, Gold Bar extended warranty, and priority product support
- Elite Gold Bar Warranty dealer — only Elite, Master Authorized and Advanced Authorized Clopay dealers can offer the extended Gold Bar installation warranty
- Houston’s largest overhead door showroom — 60+ full-size doors on display at 6631 Theall Rd including Clopay commercial models you can see and touch before you buy
- A+ BBB accredited business proudly serving Greater Houston since 1991 — over 35 years serving homeowners, builders, and commercial clients
- GHBA & TAB member — Greater Houston Builders Association and Texas Association of Builders membership; preferred by Houston-area home builders
- Factory-certified Clopay installation technicians — trained and certified on the full commercial Clopay lineup
- Same-day estimates — no-obligation project pricing delivered fast; often same day you call
- In-house installation team — no subcontractors; consistent quality and direct accountability on every Clopay installation
- Licensed, bonded & insured for commercial door work throughout the state of Texas
- Post-install service & maintenance plans for commercial accounts — annual spring inspections, lubrication, hardware checks
